Rainscreen Panels
Bespoke aluminium rainscreen systems, manufactured to drawing and supplied to site across the UK
Ready to spec your rainscreen project?
Tell us what you need — we'll help get it right before it gets to site
Start your enquiry → or call 01562 823451
About this product

METRAC rainscreen panels are bespoke aluminium fabrications, manufactured to client drawings and supplied as a complete system. From simple rainscreen cladding to complex secret fix facades, we work with specifiers and contractors from drawing review through to delivery — ensuring the right product arrives on site, on programme.

Solid aluminium is inherently non-combustible and achieves A1 classification under EN 13501-1, or A2-S1 if powder coated — meeting UK regulations for external wall surfaces on higher-risk buildings. We can advise on specification and provide supporting documentation for your fire strategy.

Panels are available in secret fix clip systems or hook-on, with individual panel removal for ongoing maintenance. Shape, panel size and thickness are all adaptable. Finishes include anodised, pre-painted and polyester powder coated aluminium across a full RAL range.

Specifications
Materials Aluminium — powder coated, anodised
Thickness 2mm – 4mm
Finish Full RAL range, mill finish
Fix system Secret fix clip, hook-on
Fire rating A1 / A2-s1,d0 (BS EN 13501-1)
Certification QUALICOAT powder coat
Bespoke sizing Yes — manufactured to drawing
Lead time Typically 10 working days
Start enquiry with these specs pre-selected →
Key features
Comprehensive range from simple flashings to complex secret fix systems
Design input and drawing review included
Individual panel removal for maintenance
Secret fix — no visible fixings once installed
Site visits available for complex projects
Available finishes
Powder coated Anodised Pre-painted Mill finish PVDF
